Samsung AR30DXFZCWKNSA 8.0 kW Aero Wall Mounted Split System | R32
Indoor: AR30DXFZCWKNSA
Outdoor: AR30DXFZCWKXSA
AI Energy Mode | In-built Wi-Fi | Energy Monitoring | 3-Step Auto Clean
8.0 kW Cooling | 9.0 kW Heating
Features
- AI Energy Mode & AI Auto Cooling
- In-built Wi-Fi with SmartThings
Specifications
|
Model Name
|
Indoor Unit | AR30DXFZCWKNSA | |
| Outdoor Unit | AR30DXFZCWKXSA | ||
|
Capacity
|
Cooling (Min/Std/Max) (kW) | 2.5/8.0/9.3 | |
| Heating (Min/Std/Max) (kW) | 2.4/9.0/13 | ||
|
Refrigerant
|
Type | R32 | |
| Factory Charging (Kg) | 2 | ||
|
Energy Efficiency
|
EER (W/W) | 3.27 | |
| COP (W/W) | 3.27 | ||
| AEER (W/W) | 3.27 | ||
| ACOP (W/W) | 3.34 | ||
| Star rating (Cooling – Hot/Average/Cold) |
3.0/3.0/3.0 | ||
| Star rating (Cooling – Hot/Average/Cold) |
3.0/2.0/1.5 | ||
|
Power
|
Power Supply (Ø, V, Hz) | 1, 220-240, 50 | |
|
Power Input (Min/Std/ Max)
|
Cooling (kW) | 0.49/2.45/3.15 | |
| Heating (kW) | 0.44/2.75/4 | ||
|
Current Input (Min/Std/ Max)
|
Cooling (A) | 2.5/11.1/14 | |
| Heating (A) | 2.3/12.5/17.5 | ||
|
Indoor Unit
|
Air Flow Rate (l/s)
|
Cooling (T/H/M/L) | 340/295/252/195 |
| Heating (T/H/M/L) | 362/328/273/218 | ||
| Sound Pressure Level (H/Silent) | 47/30 dB(A) | ||
| Net Weight (Kg) | 12.4 | ||
| Shipping Weight (Kg) | 14 | ||
| Net Dimensions (WxHxD) |
1,055mm x 299mm x 215mm
|
||
| Shipping Dimensions (WxHxD) |
1,115mm x 290mm x 375mm
|
||
|
Outdoor Unit
|
Compressor Type | BLDC ROTARY | |
| Sound Pressure Level (Cooling) | 57 dB(A) | ||
| Net Weight (Kg) | 67.8 | ||
| Shipping Weight (Kg) | 72 | ||
| Net Dimensions (WxHxD) | 940mm x 998mm x 330mm | ||
| Shipping Dimensions (WxHxD) |
995mm x 1,096mm x 426mm
|
||
|
Installation
|
Liquid Pipe, Φ, mm (inch) | 6.35 (1/4) | |
| Gas Pipe, Φ, mm (inch) | 15.88 (5/8) | ||
| Max Piping Length (Precharged), (m) | 30 (15) | ||
| Max Piping Heigh (m) | 15 | ||
| Drain Pipe (Φ, mm) | 16.3, 550 | ||
|
Additional Accessories
|
Easy Filter Plus | Removable/Washable | |
| Wi-Fi | • | ||
| Control System | Infrared remote control | Included | |
|
Operating Temperature Range
|
Cooling (℃) | -10 ~ 46 | |
| Heating (℃) | -15 ~ 24 | ||
